T343 Double-Ended Beam, NICKEL-PLATED Alloy Steel Load Cell | IP67

T343 Double-Ended Beam, NICKEL-PLATED Alloy Steel Load Cell | IP67

by Optima Scale
$629.00 - $1,499.00
$629.00
$629.00 - $1,499.00
$629.00

FREE Shipping (Lower 48 United States) Order today for delivery in 5-7 business days.

✔ Authorized Optima Scale Dealer

✔ Call Us: +1 (941) 257-3293

✔ 1 Year Manufacturer's Warranty

✔ Made in The USA

✔ Ships From Rancho Cucamonga, CA

The T343 Double-Ended Beam Load Cell is crafted from nickel-plated alloy steel and engineered with an IP67 protection rating, ensuring durability against moisture, dust, and harsh industrial environments. Perfect for heavy-duty weighing systems such as truck scales and large platform scales, it delivers dependable and accurate measurements under extreme loads. With its rugged design and consistent performance, the T343 is a reliable solution for demanding industrial weighing applications.

SPECIFICATION



MODEL NUMBER

CAPACITY

T343-25

25,000 lbs

T343-40

40,000 lbs

T343-50

50,000 lbs

T343-50-LE

50,000 LE lbs

T343-60

60,000 lbs

T343-60-LE

60,000 LE lbs

T343-75

75,000 lbs

T343-75-LE

75,000 LE lbs

T343-100

100,000 lbs

T343-125

125,000 lbs


  • Rated Capacity: lb: 25K/40K/50K/60K/75K/100K/125K
  • Rated Output: 3.0mV/V
  • Non-Linearity: ±0.03% F.S.
  • Hysteresis: ±0.02% F.S.
  • Repeatability: ±0.2% F.S.
  • Creep (30 minutes): ±0.03% F.S.
  • Temperature Effect on Span: ±0.0015% F.S./C
  • Temperature Effect on Zero: ±0.0027% F.S./C
  • Zero Balance: ±1.00% F.S./C
  • Insulation Resistance: >5000 MEGOHMS
  • Input Impedance: 700±10Ω
  • Output Impedance: 700±5Ω
  • Safe Overload: 150% F.S
  • Excitation Recommended: 10-20V AC/DC
  • Approval: CC 15-022
  • Material/Finish: Alloy Steel
  • Operation Temperature: -10°C - + 40°C (14°F - 104°F)
  • Cable Length: Standard
    20K-40K: 40ft/12m
    Double-Shielded:
    50K-125K: 60ft/18m
    Load Cell Wiring: Red........ +Excitation Black...... -Excitation Green..... +Signal
    White...... -Signal

INTERCHANGEABLE PRODUCTS

  • Airweigh: AW900
  • Artech: 80210
  • Coti Global Sensors: CG-BE40
  • Celtron: DLB

SHIPPING & SUPPORT

We offer FREE SHIPPING to Lower 48 United States

This product ships directly from USA Measurements U.S. manufacturing facility. Standard lead time is 5–7 business days to ship.

Have questions or need help choosing the right model and scale accessories?
Contact us at sales@northlinescale.com or give us a call +1 941-257-3293 — our team is here to help.
