Detecto 6854DHR Digital Bariatric Scale

Detecto 6854DHR Digital Bariatric Scale

by Cardinal
$3,650.00 - $3,740.00
$3,650.00
$3,650.00 - $3,740.00
$3,650.00

FREE Shipping (Lower 48 United States) Order today for delivery in 5-7 business days.

✔ Authorized Cardinal Scale Dealer

✔ Call Us: +1 (941) 257-3293

✔ Manufacturer Warranty

✔ Made in Webb City, Missouri, USA

✔ Ships From Missouri, USA

Detecto’s 6854DHR is engineered for weighing obese and unsteady patients and features a low-profile platform and stainless steel handrails with padded grips for patient assurance. Utilizes the Detecto 1LOOK feature for optimum performance, displaying height, weight, and BMI simultaneously by simply raising the digital height rod while a patient is being weighed. There are no keys to push and no operational sequences. EMR/EHR ready. Height rod measures up to 6’7” (200 cm). 600 lb x 0.2 lb / 270 kg x 0.1 kg capacity. Optional Wi-Fi connectivity. OIML EC Class III model available. The 6854DHR is NTEP certified for weighing accuracy with patient dosing.



    FEATURES

      • 6C Batteries (Not Included)
      • 600 lb / 270 kg Capacity
      • NTEP Certified for Weighing Accuracy with Dosing Patients
      • BMI Calculation
      • Digital Height Rod
      • EMR/EHR Ready
      • Integral Wheels Ease Transport
      • OIML EC Class III Model Available
      • Wi-Fi and Ethernet Optional



      SPECIFICATIONS


      RESOURCES

      6854DHR/6857DHR Bariatric Scale Bulletin

      6854DHR/6857DHR Bariatric Scale Bulletin (Spanish)

      EMR/EHR Connectivity Flyer

      NTEP Medical Scales Flyer




      SHIPPING & SUPPORT

      We offer FREE SHIPPING to Lower 48 United States

      This product ships directly from USA Measurements U.S. manufacturing facility. Standard lead time is 5–7 business days to ship.

      Have questions or need help choosing the right model and scale accessories?
      Contact us at sales@northlinescale.com or give us a call +1 941-257-3293 — our team is here to help.

      Compare products

      {"one"=>"Select 2 or 3 items to compare", "other"=>"{{ count }} of 3 items selected"}

      Select first item to compare

      Select second item to compare

      Select third item to compare

      Compare
      OVERVIEW

      Detecto’s 6854DHR is engineered for weighing obese and unsteady patients and features a low-profile platform and stainless steel handrails with padded grips for patient assurance. Utilizes the Detecto 1LOOK feature for optimum performance, displaying height, weight, and BMI simultaneously by simply raising the digital height rod while a patient is being weighed. There are no keys to push and no operational sequences. EMR/EHR ready. Height rod measures up to 6’7” (200 cm). 600 lb x 0.2 lb / 270 kg x 0.1 kg capacity. Optional Wi-Fi connectivity. OIML EC Class III model available. The 6854DHR is NTEP certified for weighing accuracy with patient dosing.


        FEATURES
          • 6C Batteries (Not Included)
          • 600 lb / 270 kg Capacity
          • NTEP Certified for Weighing Accuracy with Dosing Patients
          • BMI Calculation
          • Digital Height Rod
          • EMR/EHR Ready
          • Integral Wheels Ease Transport
          • OIML EC Class III Model Available
          • Wi-Fi and Ethernet Optional



          SPECIFICATIONS

          6854DHR Capacity: 600 lb x 0.2 lb / 270 kg x 0.1 kg
          6854KGEUDHR Capacity: 300 kg x 0.1 kg or 350 kg x 0.2 kg
          Platform Size: 18 x 14 in / 46 x 36 cm
          Shipping Weight: 74 lb / 34 kg
          Digital Height Rod: 43 to 79 in (110 to 200 cm)
          Power: Optional model MV1PWR AC adapter or 6 C batteries (not included)
          Display: 5 digit, seven segment, 7/8 inch (22.23 mm) high LCD weight digits
          Connectivity: RS232 serial, USB and optional wired and Wi-Fi Ethernet
          Keyboard: 19 key, color-coded, sealed membrane
          Digital Height Rod Requirements: 0.1 in / 0.1 cm graduations
          Outer Dimensions (with height rod folded down): 29.1 in W x 20.8 in D x 45.6 in H / 73.9 cm W x 52.8 cm D x 115.8 cm H

          Model

          Description

          6854DHR

          Bariatric Scale, Digital, 600 lb x .2 lb / 270 kg x .1 kg, 18" x 14" Platform, Digital Height Rod

          6854DHR-AC

          Bariatric Scale, Digital, 600 lb x .2 lb / 270 kg x .1 kg, 18" x 14" Platform, DHR, AC Adapter

          6854DHR-C

          Bariatric Scale, Digital, 600 lb x .2 lb / 270 kg x .1 kg, 18" x 14" Platform, DHR, BT / WiFi

          6854DHR-C-AC

          Bariatric Scale, Digital, 600 lb x .2 lb / 270 kg x .1 kg, 18" x 14" Platform, DHR, BT / WiFi, AC Adapter

          6854KGEUDHR

          OIML EC Class III 300 kg x 0.1 kg, Stand on Scale with DHR
